MR-WT03 Handheld Address Writer

1. Setting parameters such as the number of loaded channels, baud rate, playback speed, and the number of colors of the coder can be set;

2. Support kinds of DMX512 chips addressing , you can specify the starting channel, the load channel of a single chip, and the lamp number, you also can verify the addressing situation via automatic/manual test mode .

3. The coder has a variety of built-in test animation effects, such as multiple color gradients, automatic/manual run points, overall gradients and other effects;

4. With SD card slot, support SD card to store animation data, and can specify a certain playback scene, and can adjust the playback speed;

5. It can simulate DMX512 console, can send channel data arbitrarily for channels 1-512 of DMX512 channel, and can be used as a simple 3/25 DMX512 console to use;

6. Support standard RDM protocol, search for RDM lamps, static detection, write DXM512 address through UID, etc.

Features;

7. The coder has the color picking function on the color wheel, you can select a color value in the color wheel to control, and support a variety of four-color modes;

8. With 1 port DMX512 signal output, its addressing signal is compatible and supports differential signal mode;

9. A lithium battery with a capacity of 4480mAh is used as a power source, and it supports a Micro-B type USB interface for power feeding ;

10. With wireless remote control function, it can be connected by radio frequency to realize remote control of lamps and lanterns in a wireless way;

11. Support multiple DMX512 protocols, such as: MR-DMX05, DMX512AP, UCS512, SM16512, TM512,

SM16512, UCS512C, MR-RDM06 .
